Mokwheel Obsidian: Everything You Need to Know
Full-suspension fat bike. The cart is $1,699.99 from $2,199.99. The technical block prints rated 750W, continuous 1,000W, peak 1,300W, and 48V 19.6Ah with no watt-hours. Forty-eight times 19.6 is 940.8. A review prints a 1,500W peak and 941 Wh. A shop page says mid-drive.
By SickEBike desk
The short answer
The Mokwheel Obsidian is a full-suspension fat bike. The cart was $1,699.99 from $2,199.99. The technical block prints 750 watts rated, 1,000 continuous, and 1,300 peak, plus 19.6 amp-hours and no Wh figure. Forty-eight times 19.6 is 940.8. A review prints a rear hub, a higher peak, and 941Wh, and calls the bike unclassified. Claimed mass is 77 pounds. Scales said 81.3 and 83.4. A shop page says mid-drive.
The Mokwheel Obsidian on the US product page is a full-suspension fat bike. The cart this crawl opened was $1,699.99 from $2,199.99. A hero tile says 750W and 105 Nm-plus, a 28 mph top, up to 80 miles, and a 560 lb payload. The technical block is more specific and less tidy: rated 750W, continuous 1,000W, peak 1,300W, torque 105 Nm-plus, battery 48V 19.6Ah with no watt-hour figure, mass 77 lb, throttle to 20 mph and pedal assist to 28, range 60–80 miles. Forty-eight times 19.6 is 940.8. The fork tile says 130 mm of air. Electric Bike Report’s review calls the motor a 1,000W rear hub with a 1,500W peak, prints 941 Wh, and calls the bike unclassified. The row on the list links here.
750 rated, 1,000 continuous, 1,300 or 1,500 peak
Mokwheel’s US technical block, Electric Bike Report’s review, BikeRide’s sheet, a Portland shop page for an “Obsidian 2.0,” and a German ST card. Not averaged.
| What is printed | |
|---|---|
| US block | Cart $1,699.99 from $2,199.99. Rated 750W, continuous 1,000W, peak 1,300W, 105 Nm-plus. Battery 48V 19.6Ah, no watt-hours. Speed class: 20 mph throttle, 28 mph pedal assist. Mass 77 lb. Range 60–80 miles. Payload 560 lb. Fork tile: 130 mm air. Sensor: torque plus cadence. UL 2849 language on the page. Tire tile: 4.0 inch. |
| Review and a database | Electric Bike Report: 48V 1,000W brushless rear hub, 1,500W peak, 105 Nm, Samsung 48V 19.6Ah / 941 Wh, claimed 77 lb and 81.3 actual, claimed 60–80 miles, measured 33.5 miles in PAS 5 and 60.4 in PAS 1, fork 130 mm, rear shock 50 mm, labeled unclassified. BikeRide’s facts row says 1,000W, 19.6Ah, hub-drive, 81.3 lb, unrestricted, 80 miles. Its detailed spec says nominal 750W, a 20Ah pack written 960Wh, claimed 77 lb and actual 83.4 lb, a Class 2 sticker, and test rides of 31.85 miles at PAS 3 and 25.40 at PAS 5. Prices on that page include $1,699.99, $1,649.99, and $2,049.96. |
| A different machine, and a shop label | A Portland shop page titled Obsidian 2.0 calls the motor a 1,300W peak mid-drive and prices it at $2,199. Electric Bike Report and BikeRide both say rear hub. Germany’s Obsidian ST card is 250W, 25 km/h, 65 Nm, 940 Wh, and €1,999. That is an export cap, not a translation of the US peak. |
Do not average 750, 1,000, 1,300, and 1,500 into one motor. Rated, continuous, and peak are three words, and the review’s peak is a fourth number. Do not average 19.6 and 20 amp-hours. Forty-eight times 19.6 is 940.8, which is why a review can print 941 and a German card can print 940, while BikeRide’s 20 amp-hour line is 960. Those watt-hour figures are not interchangeable. Mass is 77 claimed, 81.3 on one scale, 83.4 on another, and a sentence that says 83. Distance is 60–80 claimed, then 33.5 and 60.4 on one test, and 25.40 plus 31.85 on another. Quote the assist. A mid-drive label on a shop page does not rewrite the review’s hub.
The US block prints 750W rated, 1,000W continuous, 1,300W peak, and 19.6Ah with no watt-hours. Forty-eight times 19.6 is 940.8. A review prints a 1,500W peak and 941 Wh, and calls it a rear hub. A shop page says mid-drive.
Who it is for
It is the full-suspension fat bike at the sale dollar, if you can stand a watt label that will not sit still and you know which shock is on the frame you clicked. It is not the Nomad 2X. That one prints 80 lb, a 1,400W peak on the hero, and 801.6Wh, and its motor cell does not say 1,000 continuous. A rear hub does not use the gears the way a crank motor would. If the shop page you opened says mid-drive, you are not looking at the bike Electric Bike Report weighed. The hub versus mid-drive page is how to tell.
Pedals are on the bike. A 750-watt rated figure is not under the federal “less than 750” line, and 1,000 watts continuous is further outside it. Throttle to 20 and pedal assist to 28 is a speed pair, not a class sticker that repairs the watts. Electric Bike Report’s word is unclassified. BikeRide found a Class 2 sticker and also filed the bike as unrestricted. The class chart is why those cannot all be true at once. The watt-hour page is why 940.8, 941, and 960 are not one pack. Buy the frame in the photo. Do not buy a European 250-watt card and expect this motor.
Questions people ask
Why are there four power numbers?+
The US block prints rated, continuous, and peak: 750, 1,000, and 1,300, at 105 newton-meters plus. A review prints a 1,000-watt rear hub and a 1,500-watt peak. A database facts row says 1,000, and its detailed spec says nominal 750. Do not collapse them.
What follows from 19.6 amp-hours?+
The US block never prints a Wh figure. Forty-eight times 19.6 is 940.8. The review prints 941. A German card prints 940 on a 250-watt, 25 km/h bike. A database detailed spec prints 20 amp-hours and 960, which is a different product. Keep the labels apart.
Which scale and which loop?+
The block says 77 pounds and 60 to 80 miles. One review scale was 81.3, with 33.5 miles at PAS 5 and 60.4 at PAS 1. Another sheet says actual 83.4, with 31.85 miles at PAS 3 and 25.40 at PAS 5. Fork travel on the tile is 130 mm of air. Quote the assist.
Can you call it Class 2?+
The review says unclassified, throttle to 20 and pedal assist to 28. A database found a Class 2 sticker and also filed the bike unrestricted. A Portland page titled as a 2.0 says mid-drive. The review says rear hub. An export card at 250 watts is not this motor. Seven hundred fifty rated is already not under the federal line.
